Characteristics: flexible, uncompromising, configurable & powerful. Editions: milling machine, mill-turn-machine, head-change machine, twin column machine & pallet changing machine.
Contact the teamMilling heads
Workpiece handling
Tool handling
CNC Systems
Accessories
Travels (max. in mm) | X axis (horizontal, longitudinal): 40.000 | |
Y axis (vertical): 4.100 | ||
Z axis (horizontal-cross): 1.600 | ||
Milling head | Universal, orthogonal milling head | |
Standard swivel range: A axis 180° | ||
C axis 360° | ||
Main drive/motor spindle | ||
Drive power in kW: up to 75/70 | ||
Speed range in rpm: up to 8.000/24.000 | ||
Speeds of movement | Feeds and rapid traverses | |
(X, Y, Z) in mm/min: up to 40.000 | ||
Acceleration in m/s² 3,5 | ||
Tool taper | SK 50 BIG-PLUS | |
HSK 100 A DIN 69893 | ||
Versions | Milling machine | |
Mill-Turn-machine | ||
Head-change machine | ||
Twin column machine | ||
Machine with pallet changer |
